SANODYE BLACK OA

Sanodye Black OA

Homogeneous, metal free, water-soluble dye for the dyeing of anodized aluminium.

Sanodye® Schwarz OA is distinguished by its high fastness to light and heat as well as by its strong
dyeing power.

Clariant (Switzerland) Ltd.
 Sanodye® Black OA
16.09.2008 1 102782
1. Dye-specific data

 Commercial form: fine granules
 Chemical character: azo dye, not metallized
 Bulking volume: 850 g/l
 Solubility in water: 20 g/l at 20°C
 Storage stability: virtually unlimited, store containers closed tightly
 Ecotoxicological data: see Safety Data Sheet.


2. Application conditions


 Concentration
temperature Dyeing Dyeing time
Standard coating thickness  (12 µm) 10 g/l 55 - 60°C 10 - 20 min
Standard coating thickness  (25 µm) 10 g/l 55 - 60°C 30 - 45 min

 pH: 5.5 ± 0,5
 Buffer: The dyebaths have to be buffered with
     8    g/l   sodium acetate trihydrate
  + 0,4 ml/l acetic acid, pH 5.6
 Water quality: preferably deionized
 Sealing: preferably with Anodal® ASL (one or two stage).


3. Preparation of the dyebath

When preparing the dyebath care must be taken that the dye is well dissolved.
The dye can be dissolved in deionized water (80 – 90°C) in a separate container (5 parts water
to 1 part dye). This stock solution is then stirred into the dyebath.


4. Lightfastness of the dyeings

 Sanodye® Black OA is distinguished by high lightfastness.
 Lightfastness of Sanodal® dyeings: rating > 8  (ISO 2135).
Clariant (Switzerland) Ltd.  Sanodye
® Black OA
16.09.2008 2 102782
5. Special remarks
 Unsealed dyeings are virtually unstrippable in diluted nitric or sulphuric acid.
 They can be  stripped in nitric acid 10 % + potassium permanganate 5 %.
 After the treatment in Potassium permanganate, neutralization must be carried out for 1-5 min
 in a sodium bisulphite 5 % solution.

Prevention of mould formation
An addition of an antimicrobial product can inhibit mould formation for a long time.
We recommend the addition of Nipacide CI 15 (See Technical Information) 25 – 50 mg/l.


6. Disposal of the dyebaths

Spent dyebaths must be disposed of; e.g. with Anodal® WT-1 Liquid. The precipitation method
is described in detail in the Technical Information bulletin for Anodal® WT-1 Liquid.

 The table below shows the additions required for precipitating Sanodye® Black OA.


Anodal WT-1 Residual    Dye reduction
Precipitation
method FeClml/g dye 3, 40% Etching lyeml/g dye Liquid dye in      in % related
ml/g dye the filtrate to conc.
mg/l dyebath
A 2.0 - 0.7 ~ 1 > 99.9
B 2.0 - 0.7 ~ 400 ~ 96
C - 2.0 0,8 ~ 3400 ~ 66
